Key Features:
• Nordson DAGE NT500 Maintenance-Free, Sealed-Transmissive X-ray Tube
• < 0.5μm (500nm) Feature Recognition Tube
• 160 kV Tube with Up to 10 W Target Power - Always Retains Sub-Micron Ability
• Nordson DAGE 2 Mpixel @ 25fps Long Lifetime CMOS Flat Panel Detector Including Real Time Image Enhancements
• Geometric Magnification 2,500 X, System 5,200 X and Total 15,600 X with Digital Zoom
• 29” x 22.8” (736 x 580 mm) Maximum Board Size
• 70° Oblique Views without Loss of Magnification
• 24” TFT LCD Monitor
• AXiS - Active X-ray Image Stabilisation
• High Quality Real Time Imaging
